Part #: INTFLEXKIT5201E

This product qualifies for quantity discount pricing

Quantity	Discount%	Discounted Base Price
2-5	5%	$1,925.64
6-20	10%	$1,824.29
21-250	15%	$1,722.94

Free FedEx Shipping and Volume Pricing

106 Years in Trailer parts Distribution

Summary

5,200 lb. electric brake Dexter® Torflex® trailer kit with sixteen-inch ST23580R16E white spoke wheels and tires, a 2" ball A-frame 50° RAM Coupler, and matching RAM A-Frame Jack.

Outside of Brackets

Hub Face Measurement (Minimum Overall Overhang 15" Maximum Overall Overhang 20") (Example outside bracket 60" hub face will be 75" to 80") (Maximum 95" hub face)

22.5° Down - No Load H 4.07" L 5.54" Full Load H 1.77" L 6.00"Shock Load H 0.60" L 5.88"

10° Down - No Load H 2.81" L 5.91" Full Load H -0.47" L 5.86" Shock Load H -0.65" L 5.49"

0° - No Load H - 1.77" L 6.00" Full Load H -0.53" L 5.54" Shock Load H -1.56" L 4.99"

10° Up - No Load H - 0.73" L 5.91" Full Load H -1.45" L 5.06" Shock Load H -2.38" L 4.33"

22.5° Up - No Load H -0.53" L 5.54" Full Load H -2.47" L 4.24" Shock Load H -3.22" L 3.33"

Cambered, Brake Flange, E-Z Lube Spindle, Low Profile Mounting Bracket in Standard Orientation, No Pre-Wire, Painted

By selecting this box, you agree this is a custom-built to order Torflex trailer axle to the specifications provided on this order form. Once the order is placed the axle cannot be altered, changed, cancelled, or returned for any reason. If you have any questions before placing this order please email [email protected] or call 1-800-866-3336

Summary

Hub Face Measurement (Minimum Overall Overhang 15" Maximum Overall Overhang 20") (Example outside bracket 60" hub face will be 75" to 80") (Maximum 95" hub face)
22.5° Down - No Load H 4.07" L 5.54" Full Load H 1.77" L 6.00"Shock Load H 0.60" L 5.88"
Cambered, Brake Flange, E-Z Lube Spindle, Low Profile Mounting Bracket in Standard Orientation, No Pre-Wire, Painted
By selecting this box, you agree this is a custom-built to order Torflex trailer axle to the specifications provided on this order form. Once the order is placed the axle cannot be altered, changed, cancelled, or returned for any reason. If you have any questions before placing this order please email [email protected] or call 1-800-866-3336

Base Price: $2,026.99

Customized Price: $2,026.99

Quantity

Description

You have selected the 5,200 lb. electric brake Dexter® Torflex® trailer kit with sixteen-inch ST23580R16E white spoke wheels and tires, a 2" ball A-frame 50° RAM Coupler, and matching RAM A-Frame Jack. We have many different lengths of axles for your trailer. We ask that you provide your desired outside frame width, hub face measurement, and starting angle when placing your order. Below is a complete bill of materials for the trailer kit you have selected.

Bill of materials for selected 5,200 lb. trailer kit:

(1) 5,200 lb. Dexter® Torflex® torsion trailer axle with electric brakes (Some assembly required)
(2) Sixteen-inch ST23580R16E white spoke wheel and tire
(1) Optronics One Diode LED Trailer light kit including taillights, clearance lights, license plate bracket, and wire with connection
(1) RAM 2" 50° A-frame coupler
(1) RAM A-frame jack
(2) Safety chains
(1) 7 Way trailer end connector
(50) 7 Way cable
(1) Breakaway kit with charger

Part Number: INTFLEXKIT5201E | Total weight: 400 lb.
